MITS ALLOY TRAYS

We make the following standard size trays for most modern makes, models and cab sizes.
Dual cab : 1765mm x 1870mm (850mm headboard)
Extra cab : 2050mm x 1870mm (850mm headboard)
Single cab :  2415mm x 1870mm (850mm headboard)

We make the following size trays for most American pick ups:

6.4FT : 2000mm x 2050mm (900mm headboard)
7FT : 2200mm x 2050mm (900mm headboard)
8FT:  2500mm x 2050mm (900mm headboard)



For photos and video of your make and model, check out the gallery.

Please note: We don’t build custom designs. All trays manufactured are our own design.

HEAVY DUTY ALLOY TRAY

100% Fully welded
CNC Cut and folded construction.
5mm 65×65 SHS headboard.
Headboard height from 850mm
CNC cut window protector
LED tail light package and number plate light
Mudguards and mud flaps

Ford Ranger fitted with 1865mm tray package - powdercoated in ebony black.
1000mm x 230mm rear under tray toolboxes fitted to an F150 - 2 Pac colour matched to vehicle paint

UNDER TRAY TOOL BOXES

Slimline push locks
Plush automotive seal
Heavy duty alloy hinges
Lengths: 800, 900 & 1000mm
Width: 180 or 230mm (USA)
Depth: 330mm
Bracket drop length: 100mm

REAR UNDER TRAY DRAWER

Rear under tray drawer with slimline push locks
225kg stainless steel slides (pair)
Fully sealed from water and dust
1500mm Long (shorter when under tray water tank is fitted)
800mm Wide
132mm Deep

1500mm rear under tray drawer fitted to 1665mm Navara tray - powdercoated in ebony black.
Full length sideboards for a 1665mm N70 Hilux tray - mill aluminium finish.

SIDEBOARDS

Strong and stylish CNC folded sideboards.
240mm tall – 35mm profile
Stainless steel hardware and hinges

Note: Short sideboards available for short canopies.

REAR LADDER RACK / LOAD BAR

Follows the profile of existing headboard
CNC mandrel bent 65x65x5mm SHS
Compatible with sideboards

Rear ladder rack fitted to 1865 Hilux tray - compatible with sideboards.
1865mm 79 series Landcruiser tray powder coated in satin black.

POWDER COATING

Powder Coating is a strong and durable way to protect and personalise your new tray
We offer all the standard Oxy Tech Colours
Take a look at their site to see the range www.oxytech.com.au

Note: Powder coat is not always an exact match for your vehicles existing paint. 2 pac paint is also available on request.

30L HEADBOARD WATER TANK

30L poly head board water tank.
MITS Alloy unique roto-moulded design.
BPA Free – drinking water compliant.
Stainless fitting kit (can be fitted to either side)

30L poly headboard water tank fitted to 1665mm Navara tray - tap kit fitted to passenger side.
70L under tray water tank fitted to 1865mm Hilux tray - rear under tray drawer is reduced to 900mm to accommodate tank.

70L UNDER TRAY WATER TANK

70L poly under tray water tank.
BPA Free – drinking water compliant.
Can be plumbed together with the 30L tank

Note: You must let us know at the time of order as they only fit with certain size rear under tray drawers.

REVERSE CAMERA RELOCATION

If your vehicle is fitted with a reverse camera we have a range of mounts to relocate it for you.

Note: You must let us know at the time of order that you want the sensors moved as we need to make provisions for them at the time of build.

Reverse camera relocation a 1665mm Hilux tray.
Reverse sensor relocation a Ranger tray.

REVERSE SENSOR RELOCATION

If your vehicle is fitted with reverse sensors we have a range of mounts to relocate them.

Note: You must let us know at the time of order that you want the sensors moved as we need to make provisions for them at the time of build.

CROSS TRAFFIC SENSOR RELOCATION

If your vehicle is fitted with cross traffic sensors we have brackets and mounts to relocate them.

Note: You must let us know at the time of order that you want the
sensors moved as we need to make provisions for them at the time of
build.

As the sensors are no longer in their factory position, they may not operate as designed. If you encounter any operational differences, please visit your dealer as they may require a recalibration.

Cross traffic sensor relocation on an Isuzu DMAX.
